Garage Plan Ref 5060ABSBCR

5060ABSBCR
Add to cart
  • Description

5m x 6m Garage Plan with a Pitch roof - Brick walls and Rendered Corner Stones Gable Sided Roof


5.6m x 6.6m Externally
30m² Ground Floor Area
12" Cavity wall construction
Single side door and window
9' x 7' Up and Over Garage Door
Truss rafter roof construction


17.5° roof pitch : Ridge Height = 3.8m
22.5° roof pitch : Ridge Height = 4.1m
30° roof pitch : Ridge Height = 4.6m
35° roof pitch : Ridge Height = 5m

This domestic double car garage is ideal for parking the family cars. This is the smallest width double garage available. The width of the garage will accommodate two cars side by side. The extra length allows for a workbench or storage area at the rear of the garage. The 9 feet wide garage door allows easy access to the garage. The cavity wall construction provides water proof construction.
