Garage Plan Ref 7070BBSBCB

7070BBSBCB
Roof Pitch and Finish *
Garage 7070B
Garage to be Mirrored *
Plan Ref 7070B
Drawing Package *
Add to cart
  • Description

7m x 7m Garage Plan with a Pitch roof - Brick walls and Brick Corner Stones Gable Sided Roof- style B


7.6m x 7.6m Externally
49m² Ground Floor Area
12" Cavity wall construction
Single side door and window
2No 6' 6" x 7' Up and Over Garage Doors
Truss rafter roof construction


17.5° roof pitch : Ridge Height = 3.9m
22.5° roof pitch : Ridge Height = 4.3m
30° roof pitch : Ridge Height = 4.9m
35° roof pitch : Ridge Height = 5.4m

This domestic two car garage is ideal for parking the family cars. The width of the garage will accommodate two cars side by side. The extra length provided allows for a workbench or storage area at the rear of the garage. The two 7 feet wide garage doors allow individual access to the garage for each car. The cavity wall construction provides water proof construction.
